AVer ProAV | MT300N NDI® Matrix Tracking Box

AVer MT300N NDI Matrix Tracking Box - Professional AV and Video Conferencing - Control Multiple PTZ Camera Experience with Automatic Voice Tracking

Streamline your video conferencing setup with the AVer MT300N NDI Matrix Tracking Box, designed to bring seamless automation and advanced voice tracking capabilities to your AVer PTZ cameras. This compact device integrates effortlessly into any IP or NDI network, connecting to cameras via AVer IP, NDI|HX2, HDMI, or USB inputs. The MT300N allows your PTZ cameras to automatically switch based on voice tracking, creating a more dynamic and professional conferencing experience. Compatible with popular platforms like Zoom Rooms, Microsoft Teams, and Google Meet, this device also supports third-party microphones to deliver high-quality audio.

Integrated Voice Tracking

With pre-installed PTZ Link software, the MT300N works flawlessly with AVer Pro AV cameras and third-party microphone systems from leading brands like Sennheiser, Shure, Yamaha, Nureva, ClearOne, and Audio-Technica. You can easily turn any AVer PTZ camera into a voice-tracking camera by setting preset points—no programming required.

Multicamera Switching

Upgrade to the Premium version of the PTZ Link license to support up to five groups of AVer cameras and microphones, enabling automatic video switching across multiple devices. The MT300N offers direct USB connectivity to AVer cameras, making it compatible with various video conferencing platforms, including Microsoft Teams, Zoom Rooms, and Google Meet. Whether you bring your own device (BYOD) or integrate it with your existing setup, the MT300N leverages its multimedia capabilities for a seamless experience.

Web-Based Remote Management

Manage your cameras effortlessly with our intuitive web-based interface. The MT300N allows for convenient remote access and management, enabling you to create personalized profiles with custom display layouts for easy access to your preferred settings.

Support for NDI|HX2

Harness the power of the NDI|HX2 format with built-in encode support, ensuring high-quality video and audio streaming for your connected devices.

Compact and Easily Mountable Design

The MT300N's small form factor allows for flexible installation options. Neatly tuck it away under a desk using the included rackmount brackets, or mount it on a server rack with an optional rackmount kit. This compact design ensures a clutter-free setup, perfect for any professional environment.

AVer MT300N Specifications

Processing:

• Switching Type: Software-based

Input:

• Video Inputs:
  • 3x HDMI Female
  • 1x RJ45 (HX, NDI) Female
  • 3x USB-A (3.0) Female
• Supported Video Formats:
  • HDMI / RJ45 / USB-A:
    • 1080p at 25/29.97/30/50/59.94/60 fps
    • 1080i at 50/59.94/60 fps
    • 720p at 50/59.94/60 fps
• Embedded Audio Input: Supports embedded audio via HDMI, RJ45, and USB-A

Output:

• Video Outputs:
  • 1x RJ45 (NDI) Female
  • 2x HDMI Female
  • 2x USB-B (3.0) Female
• Supported Video Formats:
  • HDMI:
    • UHD 4K at 25/29.97/30/50/59.94/60 fps
    • 1080p at 25/29.97/30/50/59.94/60 fps
    • 1080i at 50/59.94/60 fps
    • 720p at 50/59.94/60 fps
    • 480p at 60 fps
  • RJ45:
    • UHD 4K at 15/30/60 fps
    • 1080p at 15/30/60 fps
    • 720p at 15/30/60 fps
    • 960 x 540 at 15/30/50 fps
    • 480p at 15/30/50 fps
    • 640 x 360 at 15/30/50 fps
  • USB-B:
    • UHD 4K at 15/30 fps
    • 1080p at 15/30/60 fps
• Embedded Audio Output: Supports embedded audio via HDMI, RJ45, and USB-A

Connectivity:

• Other I/O:
  • 1x RJ45 RS-422 Input/Output
  • 1x RJ45 LAN, PoE Input/Output
• HDCP Support: No

Hardware:

• OS Compatibility:
  • Windows 7 or later
  • iPadOS 11 or later
  • macOS 10.14 or later
• Mobile App Compatibility: Yes (iOS only, App Name: PTZ Control Panel)
• Wi-Fi: Not supported
• Bluetooth: Not supported

Power:

• Power Input: 1x Barrel (12 VDC at 1.5 A)
• Power Consumption: 18 W

Environmental:

• Operating Temperature: 32 to 122°F (0 to 50°C)
• Storage Temperature: -4 to 140°F (-20 to 60°C)
• Operating Humidity: 20 to 80%
• Storage Humidity: 20 to 95%

General:

• Certifications: CE, FCC, BSMI, NCC, IC, VCCI, UKCA, EAC
• Dimensions: 8.3 x 5.9 x 1.6 inches (21 x 15 x 4.1 cm)
• Weight: 2 lbs (900 g)

Packaging Information:

• Package Weight: 5.545 lbs
• Box Dimensions: 13.9 x 9.1 x 6.2 inches

Supported Devices:

The AVer MT300N NDI Matrix Tracking Box is compatible with a wide range of professional audio systems, ensuring seamless integration for superior sound quality in your conferencing environments:

• BIAMP:
  • TesiraFORTÉ X
  • Parlé TCM-X/lXA/XEX
• Audio Technica:
  • ATND1061DAN/LK
  • ATUC-50 DU/CU
• Shure:
  • MXA920, MXA910, MXA710, MXA310, MXCW, P300
• Sennheiser:
  • TCC2, TCC M
• Nureva:
  • HDL300, Dual HDL300, HDL410, HDL310
• Yamaha:
  • Adecia RM-CG, RM-TT, RM-CR
• ClearOne:
  • CONVERGE® Pro 2 (DSP) + BMA360 (Mic)

Camera Compatibility:

The AVer MT300N ensures optimal performance with a variety of AVer PTZ cameras, offering advanced tracking and automation features:

• AVer Cameras:
  • TR530+ (V0.0.1000.47 or later)
  • PTZ310(N) / PTZ330(N) (V0.0.0000.56 or later)
  • TR333V2 / TR323NV2 / TR313V2 / TR311HWV2 (V0.1.0000.23 or later)
  • PTZ310U(N)V2 / PTZ330U(N)V2 / PTZ211 / PTZ231 (V0.0.0000.24 or later)
  • TR211 / TR315(N) / TR335(N) (V0.0.0000.24 or later)
  • TR535 (V0.0.0000.18 or later)
  • CAM550 (V0.0.8004.20 or later)
  • CAM570 (V0.0.8102.48 or later)
  • CAM520 Pro3 (V0.0.9602.18 or later)
