Verkada | SV23 indoor air quality monitoring, asset protection, vape detection and more with Ten Sensors

Verkada SV23 Environmental Sensor – Comprehensive Environmental Monitoring for Indoor Spaces

The Verkada SV23 Environmental Sensor offers comprehensive monitoring of indoor environments with ten onboard sensors, providing insights into air quality, temperature, humidity, carbon dioxide (CO2) levels, and more. With the SV23, users can monitor critical indoor conditions in real-time and receive customizable alerts in less than 1 second. This ensures a proactive response to changing environmental conditions, helping protect spaces and improve air quality.

Designed for accuracy, speed, and security, the SV23 provides organizations with the tools to monitor, understand, and act on complex environmental conditions. The programmable alerts for each sensor reading are configured through Verkada Command, allowing easy customization based on specific thresholds. Data is stored on-device for up to 365 days, providing a long-term view of environmental trends.

The SV23 has a durable, vandal-resistant design that can be easily mounted on walls or ceilings, making it suitable for locations such as open office areas, bathrooms, locker rooms, server rooms, and more. The sensor is PoE-powered, enabling quick and efficient installation.

Comprehensive Monitoring with Ten Onboard Sensors

The SV23 Environmental Sensor is equipped with ten sensors, capturing detailed information such as temperature, humidity, air quality index (AQI), CO2 levels, particulate matter (PM2.5, PM4, PM10), motion, vape index, and more. These sensors provide a complete view of indoor air quality, helping identify environmental risks that might otherwise go unnoticed.

Real-Time Alerts and Customizable Thresholds

The SV23 supports programmable alerts for each measurement, ensuring users are notified of critical changes as they occur. These alerts can be sent via SMS and email, providing timely updates for improved safety and response.

Scalable and Easy to Install

The SV23's vandal-resistant design allows for easy installation on walls or ceilings. The PoE-powered device can be deployed in minutes, providing a hassle-free solution for monitoring various indoor spaces. It integrates seamlessly with Verkada Command, allowing for centralized management and monitoring of all environmental sensors.

Product Specifications

• Dimensions / Weight:
  • Length: 170mm / 6.69 in
  • Width: 169.5mm / 6.67 in
  • Height: 48mm / 1.88 in
  • Weight: 554 g / 19.54 oz
• Power:
  • Consumption: 4W
  • Input: IEEE 802.3af PoE
• Connectivity: RJ-45 cable connector for Network/PoE connection
• Operating Range:
  • Temperature: -5°C to +45°C (23°F to 113°F)
  • Humidity: 0 - 95% (non-condensing)
• Sampling Frequency: Every 5 seconds
• Device Storage: Up to 365 days
• Cloud Storage: Up to 365 days (audio excluded SV25 only)
• Compliance & Safety: FCC Part 15B, ICES-003, CE, UKCA, VCCI, NDAA
• Included Accessories:
  • Mounting plate
  • Installation kit (T10 security Torx screwdriver, mounting screws, washers, drywall anchors & wing nuts)
• Anticipated Installation Locations:
  • Server room closets, open office areas, bathrooms/locker rooms, closed rooms, manufacturing floors, hard goods storage facilities

Environmental Sensors Details

• Temperature Sensor: CMOS
  • Operating Range: -5 to 45°C (23 to 113°F)
  • Typical Accuracy: ± 1°C
• Humidity Sensor: CMOS
  • Operating Range: 0 - 95% non-condensing
  • Typical Accuracy: ± 3% @ 25°C
• CO2 Sensor: Photoacoustic
  • Range: 0 - 40,000 ppm
  • Typical Accuracy:
    • 400 ppm - 1000 ppm ± 75 ppm
    • 1001 ppm - 2000 ppm ± (40 ppm + 5% of reading)
• Particulate Matter (PM2.5, PM4, PM10): Laser scattering optical sensor
  • Range: 0 - 1000 μg/m3
  • Typical Accuracy:
    • PM2.5: ± 25 μg/m3 + 5 % m.v (0 - 100 μg/m3)
    • PM4/PM10: ± 25% m.v. (100 - 1000 μg/m3)
• Air Quality Index: U.S. Air Quality Index, derived from multiple sensors
  • Range: 0 - 500
• Vape Index: Proprietary formula derived from multiple sensors
  • Range: 0 - 100
• Motion Sensor: Passive Infrared (PIR)
  • Field of View: 120°
• Noise Level Sensor: MEMS Microphone
  • Range: 20 - 120 dB SPL (A-Weighted)
  • Typical Accuracy: ± 5 dB

What's in the Box

• Verkada SV23 Environmental Sensor
• Mounting plate
• Installation kit with T10 security Torx screwdriver, mounting screws, washers, drywall anchors & wing nuts
• Limited 10-Year Manufacturer Warranty
