Highlights
- AI-assisted Auto Framing and Person Tiling help keep meeting participants properly represented in the video image.
- Six MEMS microphones with linear beamforming and a published 4.5 m microphone reach support pickup across typical medium-room table layouts.
- Four full-range stereo speakers and integrated DSP with room-acoustic optimization provide an all-in-one audio endpoint.
- Dante-based expansion supports additional Sennheiser microphones when the room requires more audio coverage.
- USB/BYOD operation lets the connected notebook, PC, or room computer supply the conferencing application and compute.
- Wall, tabletop, freestanding, and optional VESA mounting give installers flexibility when positioning the bar.
Ideal For
- Small-to-medium corporate conference rooms
- Medium meeting rooms for up to 12 participants
- BYOD rooms where users connect a notebook or PC for meetings
- Rooms requiring expandable microphone coverage through Dante
- Multi-room deployments managed through centralized device tools
Resources
Sennheiser TeamConnect Bar M 4K Dante All-in-One Video and Audio Solution for Medium Conference Rooms
The Sennheiser TeamConnect Bar M combines a UHD 4K ePTZ camera, six-microphone beamforming array, four full-range stereo speakers, and built-in DSP in one conference-room bar. It is intended for small-to-medium meeting rooms where clear room audio, wide-angle video, and automatic participant framing are more practical than assembling separate camera, microphone, and speaker components.
It is best suited to rooms up to approximately 15 x 20 feet with as many as 12 people. The bar connects by USB to a notebook, PC, or room computer for conferencing applications, so it does not include integrated room compute or run meeting platforms independently. Dante networking supports audio expansion, while wall, tabletop, freestanding, and optional VESA mounting accommodate different room layouts.
Sennheiser TeamConnect Bar M - All-in-One Video and Audio Solution for Medium Conference Rooms
Platform Compatibility
- Some functions, including Bluetooth and Wi-Fi, are deactivated in standard USB-only mode until enabled in Sennheiser Control Cockpit.
- Certification is documented with the listed ClickShare and device firmware versions.
- Use the certified firmware and current Microsoft Teams Rooms program requirements shown by Microsoft.
Key Specifications
- Camera: ePTZ with AI-assisted Auto Framing and Person Tiling
- Camera resolution: UHD 2160p (4K)
- Camera field of view: 115° horizontal and 120° diagonal
- Microphones: Six MEMS microphones with linear beamforming array; 23 static beams
- Integrated speakers: Four full-range stereo speakers
- Audio frequency response: 100 Hz to 18 kHz
- Published microphone reach: 4.5 m
- DSP: Automatic room-acoustic optimization, auto-mixing, and multi-AEC
- Connections: USB-C, USB-A, two RJ45 Ethernet ports, two HDMI 2.0 outputs, and DC input
- Network and wireless connectivity: Dante, Wi-Fi, and Bluetooth 5.1
- Video outputs: Two HDMI 2.0 outputs; HDMI carries video to an external display, while the bar remains the audio device
- Mounting: Wall mount, tabletop, freestanding, or optional VESA accessory
- Power: 18 V DC input; maximum power consumption 72 W; power supply included
- Dimensions: 750 x 95 x 71 mm (length x height x width)
- Product weight: 2,500 g
- Security: Encrypted control communication and password protection by default
What's Included
- TeamConnect Bar M
- Mounting bracket and drilling template
- Power supply unit
- RC TC Bar remote with bracket and storage
- Magnetic lens cap
- HDMI cable
- USB-C 3.1 cable
- Mounting screws and installation hardware
- Two AAA 1.5 V batteries
- Manual
Compatibility
- Meeting and collaboration platforms: Certified for Microsoft Teams and Zoom when used through a connected host computer or appropriate room-compute workflow; other meeting applications, including Google Meet, use the host computer rather than running natively on the bar.
- AV and room-system integration: Connects to a host computer by USB and to displays through dual HDMI 2.0 outputs. HDMI provides video only; the TeamConnect Bar M provides the room audio.
- Microphones and audio expansion: Supports Dante-based expansion for additional Sennheiser microphones. External audio and room design should be evaluated if the table or participant area exceeds the published coverage.
- External camera expansion: A third-party PTZ camera can connect through USB-A. Intelligent switching between the internal and external cameras is not available.
- Network and management: Supports Dante networking, two RJ45 Ethernet connections, Wi-Fi, and Bluetooth 5.1. Sennheiser Control Cockpit supports network control and configuration, while Sennheiser DeviceHub provides cloud-based control for TeamConnect Bars.
- Required compute and room devices: A notebook, PC, or room computer is required for conferencing applications because the standalone bar does not include integrated room compute. An external display is required if participants need to view meeting content or remote participants on a room screen.
- USB content sharing: DisplayLink supports connecting multiple monitors through USB; the host operating system may require the appropriate DisplayLink driver.
Licensing, Warranty & Support
No subscription is required for standalone USB/BYOD operation. The connected computer must provide the conferencing application, and any Teams Rooms license, other room-platform license, or third-party software license is separate and is not included with the bar. Optional Sennheiser cloud-management features should be reviewed separately for current commercial terms. Sennheiser provides a 3-year warranty. Sennheiser provides technical support, an answer center, repair and spare-part resources, service-partner support, firmware, manuals, Control Cockpit software, and third-party integration documentation. We can help determine the room-computer, display, accessory, and licensing requirements for the intended deployment.
VideoConferenceGear.com Assistance
We can help validate whether the TeamConnect Bar M fits your room size, participant layout, conferencing platform, and audio-coverage requirements. We can also select the appropriate room computer, display, VESA accessory, Dante expansion, and licensing; coordinate installation across one or multiple locations; and provide ongoing support for the deployed system.
Common Questions
Does the standalone TeamConnect Bar M include a computer or run Teams and Zoom natively?
No. The standalone bar is a USB/BYOD room peripheral, so a connected notebook, PC, or room computer supplies the conferencing application and compute. Microsoft Teams and Zoom are certified for the exact TC Bar M configuration when used through the appropriate host-computer workflow.
What room size is the TeamConnect Bar M intended for?
It is intended for small-to-medium meeting rooms of approximately 15 x 20 feet, with up to 12 people. The published microphone reach is 4.5 m, so larger rooms or longer tables may require Dante microphone expansion or a different system design.
Can I add microphones or an external camera?
Yes. Dante supports expansion with additional Sennheiser microphones, and a third-party PTZ camera can connect through USB-A. The internal and external cameras do not switch intelligently between one another.
What mounting hardware and accessories are included?
The package includes a mounting bracket and drilling template, and the bar can also be placed on a tabletop or used freestanding. VESA mounting requires an optional VESA accessory.
Is a subscription required, and what warranty is provided?
No subscription is required for standalone USB/BYOD use, and the current Sennheiser US product page lists a 3-year warranty. The conferencing application, room-platform license, and any third-party software used by the host computer are separate.
