Highlights
- All-in-One design video conferencing applicance designed for larger rooms
- Pro 100 MP camera system with wide and tele cameras
- Wakeup sensor (radar)
- 3 full-range speakers ready for directional and stereo sound plus woofers, 4 tracking mics and 16 microphones in a beamforming array
- Ready to Use with Zoom or Microsoft Teams
- Click for Spec Sheet
Neat Bar Pro - the smart video conferencing appliance
With Neat Bar Pro, you can finally eliminate those hogging and blocking problems at meetings by providing each person with their own screen. Capable of driving three large screens at the same time, it allows your team to have an incredibly immersive higher-quality experience during any Zoom or Microsoft Teams meeting space.
Whether you're leading a seminar or a small meeting space, Neat Bar Pro's two extreme resolution cameras and advanced image depth sensor deliver 16x zoom so you can see everyone in full close-up, no matter where they are in the room.
Easy Installation and Setup
Neat Bar Pro is everything you need to transform any conference room into a dynamic place for collaboration. Just plug in the two cables, and Neat Bar Pro automatically pairs with Neat Pad, our dynamic controller and scheduler, which comes as a package with Neat Bar Pro. Both devices can be connected wired or wirelessly to your network, so you can seamlessly share audio and visual content wirelessly or via an HDMI cable. In the future, Neat Bar Pro will also be audio extensible, giving you the option of connecting it to any of your existing ceiling mics and speaker systems. Finally, if you wish, you can deploy extra Neat Pad controllers throughout large rooms - empowering additional people to start a meeting or tap mute.
Intelligence Built In
With Neat Symmetry, everyone sees everyone else’s video feeds in a way that’s natural and comfortable. It restores symmetry between people who are in the room and those remote. Neat Symmetry makes your remote colleagues feel like they are in the same room with you, while also allowing them to see the rest of the team individually up close on their screens. This intuitively frames and tracks each in-room participant, allowing them to stand up to stretch or move around for better wellbeing while remaining engaged. As a result, people stay more energized, focused, and productive for longer.
Brilliant Audio Experience
Neat Bar Pro is the next-generation video conferencing system that clears up sound and automatically detects, framer and tracks a person to ensure they are always in view. With its multiple microphone arrays, you can hold videoconference meeting regardless of room size or shapes. And at the same time, Neat Boundary enables you to set the width and depth of your meeting space to avoid the camera accidentally detecting, auto-framing and tracking anyone not involved in your video call. So, if you're in an office with glass walls and someone outside walks past or people are standing around, the camera ignores their presence. Likewise, if you're in an open-plan office, the device won't be confused by other activities happening around you
Features for Your Office Environment
Keeping a clean, safe and well-ventilated workspace is crucial to maintaining a healthy indoor environment. The Neat Bar Pro is a powerful air quality monitor that utilizes the latest AI technology to monitor CO2 levels, indoor humidity, temperature and more. It also includes Neat Sense, which allows you to monitor your office's social distancing using real-time occupancy sensors and other features.
Specifications
General
- Wakeup sensor (radar)
- Depth sensor (time-of-flight VGA 60° FOV)
- Orientation sensor (accelerometer)
- Ambient light sensor
- Camera LED
- System LED
- Tripod mount compatible (1/4-20 UNC threads)
- Table stand, wall mount and screen mount
- Security lock slot (Kensington compatible)
- Secure boot
- Triple screen support
- Sensors for temperature, humidity and air quality
Video
- Pro 100 MP camera system with wide and tele cameras
- Wide camera: 50 MP, ƒ/2.8 aperture, 113° horizontal field of view
- Tele camera: 50 MP, ƒ/1.8 aperture, 70° horizontal field of view
- Hybrid zoom up to 16x
- Automatic people framing
- Hardware accelerated video encode and decode
- Distortion correction
- Noise reduction
- Chromatic aberration correction
- Automatic white balance and color correction
- People video resolution: Up to 1080p / 30
- Content video resolution: 720p / 60, 1080p / 30
Audio
- Speakerbox for maximal tonal range with minimal distortion
- 3 full-range speakers ready for directional and stereo sound
- Woofers with two opposing drivers for vibration cancellation
- 4 tracking mics
- 16 microphones in a beamforming array
- Hardware accelerated audio processing
- Ultrasonic support for wireless content sharing
- Echo cancellation
- Noise suppression
- Automatic gain control
- Dereverberation
Electrical and environmental requirements
- 100-240V ~ 50/60Hz 1.2A
- Ambient operating temperature: 32° to 95° F (0° to 35° C)
- Storage temperature: -4° to 140° F (-20° to 60° C)
- Relative humidity: 10% to 90%
- Built-in power supply
- Power consumption
- Idle: 6W
- In call: 8-15W
Networking & ports
- WiFi
- AC power (internal power supply)
- Ethernet
- USB-C for input when connected to a touch screen
- 3x HDMI out for external screens
- HDMI-in for screen sharing
- Auxiliary port for 3rd party audio extensions (RJ45)
Size & weight
- Width: 35.04 inches (890 mm)
- Height: 3.15 inches (80 mm)
- Depth: 3.15 inches (80 mm)
- Weight: 6.83 pounds (3.1 kg)
In the Box
Neat Bar
- HDMI cable (6.5 feet / 2 meters)
- Ethernet cable (9.8 feet / 3 meters)
- Power cable (9.8 feet / 3 meters)
- Mount adapter, wall mount, screen mount and table stand
- 4 × M8 screw (0.94 in / 24 mm) for VESA mount
- 4 × M6 screw (0.94 in / 24 mm) for VESA mount
- 2 × spacer (to secure parallel TV mount)
- 1 × 5 mm hex key for the screen mount
- 1 × 2 mm hex key for the mount adapter
- 2 additional screw bags for dual or triple screen setup
- 4 × M8 screw (0.94 in / 24 mm) for VESA mount
- 4 × M6 screw (0.94 in / 24 mm) for VESA mount
- 4 × spacer (to secure alignment of all screens)
Neat Pad
- 2 × Ethernet cable (9.8 feet / 3 meters + 16.4 feet / 5 meters)
- PoE power adapter
- Mount adapter, side mount and wall mount
- 4 × M4 screw (0.39 inches / 10 mm) for the wall mount
- 3 × M4 screw (0.26 inches / 6.7 mm) for the side mount
- 2 mm hex wrench
- 5 mm hex wrench
Warranty Information
Neat Pulse Warranty and Service Plans
Optional Extended Service + Maintenance Plans Available
- Pulse Started Included in Purchase at No Cost
- Pulse Plus (1, 3, 5 Year)
- Pulse Pro (1, 3, 5 Year)
For More Info Visit https://neat.no/neat-pulse-terms-and-conditions/
